Functional Location

How to create a new Functional Location:

After accessing the Sequor MTC Functional Location app, the user will enter Grid/List mode, which lists all Functional Location entries, giving the user the ability to create a new entry or edit an existing one. To Create, click on the button and then fill in the fields:

In the Header:

• 1 - Functional Location *,
• 2 - Functional Location Description

In the General tab:

• 1 - Latitude *,
• 2 - Longitude *,
• 3 - Altitude *,
• 4 - Superior Functional Location,
• 5 - Functional Location Category

note

Items with * are required.

Functional location is an element that contextualizes other entries. Its main features are spatial contextualization, where the functional location contains geographic coordinates to provide spatial points on maps.

Or it is also widely used for organizational context, where the functional location contains the structure of the organizational sections and provides information about which node is the linked resource.

Examples:

space

• Name: Groupe SNEF (Marseille)
• Latitude: 43.33722651104153
• Longitude: 5.367064750343118 organizational
• Name: Sequor Brasil (Canoes)
• parent's name: Sequor Brasil

How to edit a Functional Location:

After accessing the Sequor MTC Functional Location app, the user will enter Grid/List mode, which lists all Functional Location entries, giving the user the ability to create a new entry or edit an existing one.

To Edit the entry:

• 1 - select the desired entry by clicking on the respective check box ,
• 2 - click on the button and edit the possible fields:

Description of Functional Location, Latitude , Longitude , Altitude *, Superior Functional Location, Functional Location Category.

Functional Location Entry Structure

General Guide

In the general guide, the user will find all the general information about the Functional Location entry.

Nr.	Field	Description	Example
	Functional Location	Enter the functional location number	FL-0101
	Description of functional location	Insert description of functional location	Groupe SNEF (Marseille)
	Latitude	Insert Latitude	43,33722651104153
	Longitude	Insert the longitude	5,367064750343118
	Altitude	Enter Altitude	0
	Superior Functional Location	Select superior functional location	Groupe SNEF (Global)
	Functional Location Category	Select Functional Location category	Main group

note

Altitude information is entered for 3D view only, to view Location on map, only Latitude and Longitude are required.
